WEB Reader

 The Web reader is able to handle multiple connections simultaneously. This makes possible to access control via HTTP calls with a free Wi-Fi TCP Client / Server for direct dialogue with the Ivrea Protocol Systems common to all OEM boards. Also it manages protocols as HTTP / SNMP / DNS / DHCP and the reader can receive power supply using POE which makes this reader easy to integrate with the most advanced networks
The reader also integrates a small internal memory and a clock for small local access controls.
The SNMP protocol allows to auto update the hour if the player is connected to the Internet.



Specifications


ModelWeb_Reader
Display16 alphanumeric characters for 2 lines (84mm x 44mm) with RGB backlight
Supported ReadersRfid 13.56 Mhz(ISO 14443 ISO 15693) , 125KHz e NFC
Barcode reader option
Imager for 2D code option
Input / OutputTurnstiler relay
Turnstile input
Three high intensity light mangement
Three high intensity led mangement
Acoustic signalBuzzer
Memory

Internal memory to storeabout 400 codes.
Integrated Clock to handle local hour.

ConnectionsRS232/TTL
Ethernet 10/100
Power Supply

12-24 Volt Ac/Dc, POE (option)

Dimensions120x45x30 mm
